PS Series
Self-priming water pumps with a very high hyd raulic
performance and a considerable pressure capacity
Able to pump up to 9 mt depth and work perfectly even in soda-water
Suitable for water lifting and distribution in
domestic fittings by small and medium sized tanks
Operating Conditions
Max working Pressure 4.0bar
Liquid temperature up to 60℃
Ambient temperature up to 40℃
Total suction lift up to 9mt.
Continuous duty
Motor
Two-pole induction motor(n=2850r, p. m)
Insulation class B
Protection I P44
Material
Pump body: Cast iron
Motor Support: Cast iron
Motor housing: Cast iron
Impeller: Brass
Shaft with rotor: 45# Steel, AlSI 416 stainless steel if request
Mechanical seal: Carbon/Ceramic
Single phase 220V-240V/50HZ
Single phase 110V-127V/60Hz If request
Single/three phase 220 V/60Hz If request
