Application
Submersible sewage pumps widely used in agriculture,
architecture, mine, environment protection and industry.
such as drainage slurry, waste water, which contained
short fibre, long fibre, wastepaper, sand and so on
it is also an ideal equipment for irrigation
Operating conditions
The maximum deep it is allowed
in water is 5m from its center of impeller;
Max. medium temperature: +40℃;
Trans mediums PH: 4-10
Kinematics viscosity of the trans medium is
7X10-7-23x10-8m2/s;
Density of the trans medium limit:
1. 2x103kg3/m
Motor
Closed, externally ventilated
Insulation class B
Protection Ip68
Material
Pump body: Cast iron
Impeller: Cast iron
Shaft with rotor: Superior steel
Mechanical seal: stainless
steel/Carbon-ceramic
Thermal protector
Motor housing: Stainless steel
Single phase 220V-230V/50Hz
Three phase 380V/50Hz
Three phase 220V/440/60Hz if request
